1700 Vynil Electric Tape

Short Description:

Vinyl Electrical Tape 1700 is a good quality, economical general purpose vinyl insulating tape.

  • Model: DW-1700
  • Product Detail

    Product Tags


    It has excellent resistance to: abrasion, moisture, alkalies, acid, copper corrosion and varying weather conditions. It is a polyvinyl chloride (PVC) tape that is flame-retardant and conformable. 1700 Tape provides excellent mechanical protection with minimum bulk.

    Thickness 7 mils (0.18 mm) Insulation Resistance 106 Megohms
    Operating Temperature 80°C  (176°F) Breaking Strength 17  lbs/in (30 N/cm)
    Elongation 200% Flame Retardant Pass
    Adhesion To Steel 22  oz/in (2.4 N/cm) Standard Condition >1000  V/mil (39.4kV/mm)
    Adhesion To Backing 22  oz/in (2.4 N/cm) After Humidity Condition >90%  of Standard





    ● Primary electrical insulation for most wire and cable splices rated up to 600 volts

    ● Protective jacketing for high voltage cable splices and repairs

    ● Harnessing of wires and cables

    ● For indoor or outdoor applications

    ● For above or below ground application
