UY Butt Connector

Short Description:

The UY Connector is a butt type, moisture resistant connector accepting two solid copper wires. It employs an insulation displacement contact (IDC) so that stripping of the conductor insulation prior to installation is not required. The UY Connector is easily installed and crimped by using our DW-8021 Connector Crimping Plier.


  • Model: DW-5021

    • Product Detail

    Product Tags

    • Butt connector UY, UY2, two wire joints on copper telephone drop wire.
    • It is applied to telephone wiring connection.
    • The butt connector is designed for 0.4mm-0.9mm copper wires with max insulation diameters 2.08mm.
    • The connector is filled with a moisture resistant compound in order to provide moisture proof connections.
    • The connector can provide total environmental sealing around IDC-contacts.
    • All materials used in the connectors shall be non-toxic and dermatologically safe.
    • Moisture-resistant test passed.
